Pre-Accelerated Pre-Thixotropic Epoxy Vinyl Ester Resin with Low Shrinkage

Basic Info

Model NO.	INV-V440
Molecular Principal Chain	Carbon Chain Polymer
Tensile Strength (MPa)	80
Tensile Modulus (Gpa)	2.9
Elongation at Break (%)	4.5
Bending Strength (MPa)	125
Flexural Modulus (Gpa)	3.0
Impact Toughness (Kj/M2)	15.5
Package Size Per Unit Product	50.00cm * 100.00cm * 50.00cm
Gross Weight Per Unit Product	220.000kg
Transport Package	IBC Tank(1100kg) or Drum(220kg)
Specification	Can be customized
Trademark	Rule
Origin	Changzhou China
HS Code	3907910000
Production Capacity	50000kg

Product Description

Product Description
Brief introduction:
Epoxy vinyl ester resin is prepared by the chemical reaction of epoxy resin and methacrylic acid through ring-opening addition. It retains the basic segment of epoxy resin, and has the good process performance of unsaturated polyester resin. After curing under suitable conditions, it shows some special excellent properties.

Features:
The standard bisphenol A epoxy vinyl resin is a vinyl resin synthesized by the reaction of methacrylic acid and bisphenol A epoxy resin. It has been dissolved in styrene solution. The specific molecular structure is shown in the figure below.Properties:
INV-V440 is a pre-accelerated, pre-thixotropic, low shrinkage vinyl resin with the following characteristics:1. Good glass fiber wettability, convenient construction;2. Low shrinkage, good dimensional stability and smooth surface;3. High toughness, crack resistance, high heat resistance temperature, and excellent strength retention rate at high temperature.
Matters needing attention:1. The transportation shall comply with the regulations on the transportation and handling of hazardous chemicals in Chapter V of the State Council's "Regulations on the Safety Management of Chemical Hazardous Substances".2. The product should be stored in a cool place below 25ºC, avoid fire and isolate the heat source.3. The shelf life is 3 months under the specified storage conditions.Product Parameters
Liquid resin properties (25ºC):

Project	INV-V440	Testing method
Appearance (visual inspection)	purple cloudy liquid	GB/T 8237
Viscosity (mPa.s)	250-350	GB/T 7193
25ºC gel time (min)*	15-55	GB/T 7193

*The curing agent uses AKZO M-50, and the dosage is 2%.

Physical properties of resin castings:

Project	Test value	Testing method
Tensile strength (MPa)	80	GB/T 2567
Tensile Modulus (GPa)	2.9	GB/T 2567
Elongation at break (%)	4.5	GB/T 2567
Bending strength (MPa)	125	GB/T 2567
Flexural Modulus (GPa)	3.0	GB/T 2567
Impact toughness (KJ/m2)	15.5	GB/T 2567
Barco hardness	38	DSC 10ºC/min
Heat distortion temperature (ºC)	105	GB/T 1634

Note: 1) the casting system sample method is implemented according to GB/T 8237;the casting body curing system: curing agent M-50 1.5%; 2) Post-curing treatment of the casting body: room temperature × 24 hours + 60 ° C × 3 hours + 120 ° C × 2 hours.Our AdvantagesRecommended Products

Item No.	Gel Time(25ºC)Min	Chemical Category	Features	Application
INV-V411	10-17	Bisphenol A	Excellent construction technology; excellent corrosion resistance, good corrosion resistance to general acids, alkalis, salts and organic solvents; high solid content, excellent mechanical and mechanical properties	Chemical anti-corrosion equipment, engineering, sporting goods, transportation.
INV-V411M	8-18	Bisphenol A	Standard bisphenol A type epoxy vinyl ester resin. Excellent construction technology, excellent corrosion resistance	Widely used in chemical engineering of many chemical media such as acid, alkali, salt, organic solvent and pipes, tanks, towers, tanks, pools in industry.
INV-V411W	20-30	Bisphenol A	Excellent corrosion resistance, combined with performance and cost advantages, with better price/performance ratio	Anticorrosion equipment and engineering in conventional chemical industry.
INV-V411L- GXX	30-120( can be customized)	Bisphenol A	Has lower viscosity, adjustable gel time, lower exothermic peak	Vacuum infusion molding process to prepare composite products, such as boats, wind power fields
INV-V416	8-14		High reactivity, heat resistance, excellent toughness	Rapid pultrusion to prepare rods, cores, pipes and other products
INV-V440	15-55		Low cure shrinkage, pre-acceleration, anti-sag	Preparation of composite molds, or composite products with low shrinkage requirements
INV-V480	----	Mgo Thickening	High reactivity, thickening with magnesium oxide	SMC molding process to prepare battery shells, fan impellers, etc.
INV-V495	----	Mgo Thickening	High toughness, magnesia thickener	Used together with low shrinkage agent, it can prepare products with low shrinkage, high strength, high toughness, high heat resistance and heat aging resistance, etc. It is suitable for BMC, SMC, prepreg and other molded products. e.g. composite toe caps, helmets.
INV-V650	30-60(can be adjusted based on the accelerator content)	Halogen Free Flame Retardant	Halogen-free, in addition to the corrosion resistance of conventional epoxy vinyl ester resins, it also has good flame retardancy. It is an integrated solution product with anti-corrosion and flame retardant properties.	Mainly used in corrosion-resistant equipment with flame retardant requirements, such as wet electrostatic precipitators in thermal power plants, chimneys, etc.
INV-V470	10-30	Phenolic Aldehyde	Phenolic modified epoxy vinyl ester resin, high crosslinking density, HDT=145 ºC, has more excellent heat resistance and corrosion resistance; especially in acid oxidizing environment, it has long-term resistance.	Heavy-duty anti-corrosion fields with strong corrosiveness and high temperature in chemical engineering and industry.
